Features of High-speed HF Power

• Energy Efficient: Resistor-free design saves up to 70% power with less than 1kW consumption, utilizing a standard single-phase supply.
• Enhanced Reliability: Reduced internal heat generation significantly lowers the malfunction rate of electrical components within the CNC EDM cabinet.
• High Performance: Supports cutting currents up to 15A and speeds up to 350mm²/min, with stable continuous cutting at 6~8A.
• Low Consumable Wear: Optimized for longevity; molybdenum wire wear is approximately 0.01mm after 500,000mm² of cutting.
• Industrial Grade: Built with a highly integrated PC/104 motherboard and double-impulse circuit design for maximum stability.
• Superior Finish: High-speed sampling and logical circuits provide precisely controlled discharging for improved surface quality.
• Versatile Cutting: Handles workpiece heights from 1mm to 1500mm without discharging interference or solution contamination.
• Smart Protection: Features high-speed signal filtering to prevent electric arcing and dedicated protection against wire burning.
